Home Hard Drives IDE Drives Western Digital Caviar WD400BB 40GB 7200 RPM 2MB Cache

Western Digital Caviar WD400BB 40GB 7200 RPM 2MB Cache

$17.77

Western Digital Caviar WD400BB 40GB 7200 RPM 2MB Cache IDE Ultra ATA100 / ATA-6 3.5″ Hard Drive Bare Drive

Only 1 left in stock

SKU: WD400BB Categories: ,

Description

This is a used Hard Drive WD400BB in good working condition.

General

  • Bytes per Sector:  512
  • Interface:  ATA-100
  • Buffer Size:  2 MB
  • Weight:  1.32 lbs
  • Manufacturer:  Western Digital Corp.

Power Device

  • Type:  none

Miscellaneous

  • Package Type:  Retail
  • Mounting Kit:  Not included

Expansion & Connectivity

  • Connections:  1 x storage – ATA-100 – 40 pin IDC

Hard Drive

  • Form Factor:  3.5″ x 1/3H
  • Interface Type:  ATA-100
  • Spindle Speed:  7200 rpm
  • Hard Drive Type:  internal hard drive
  • Form Factor (Short):  3.5″
  • Form Factor (metric):  8.9 cm x 1/3H
  • Form Factor (Short) (metric):  8.9 cm
  • Storage Interface:  ATA-100
  • Interface:  ATA-100
  • Average Seek Time:  8.9 ms
  • Max Seek Time:  18 ms
  • Track-to-Track Seek Time:  2 ms
  • Average Latency:  4.2 ms
  • Data Transfer Rate:  100 MBps
  • Internal Data Rate:  50 MBps
  • Buffer Size:  2 MB
  • Bytes per Sector:  512 Hz
  • Non-Recoverable Errors:  1 per 10^14
  • Start / Stop Cycles:  40000

Performance

  • Internal Data Rate:  50 MBps
  • Seek Time:  8.9 ms (average) / 18 ms (max)
  • Drive Transfer Rate:  100 MBps (external)
  • Average Latency:  4.2 ms
  • Spindle Speed:  7200 rpm
  • Track-to-Track Seek Time:  2 ms

Storage Controller (2nd)

  • Type:  none

Software & System Requirements

  • Software Included:  Drivers & Utilities

Environmental Parameters

  • Vibration Tolerance:  0.25 g @ 5-500 Hz (operating) / 4 g @ 20-500 Hz (non-operating)
  • Max Altitude Operating:  9840 ft
  • Min Operating Temperature:  41 °F
  • Max Operating Temperature:  131 °F
  • Humidity Range Operating:  5 – 85%
  • Sound Emission:  35 dBA

Storage Hard Drive

  • Compliant Standards:  S.M.A.R.T.

Header

  • Brand:  WD
  • Product Line:  WD Caviar
  • Model:  WD400BB
  • Localization:  English
  • Packaged Quantity:  1
  • Compatibility:  PC

Interface Required

  • Connector Type:  40 pin IDC
  • Gender:  female
  • Connector Qty:  1
  • Total Qty:  1

Bay Required

  • Type:  internal
  • Form Factor:  3.5″ x 1/3H
  • Form Factor (metric):  8.9 cm x 1/3H
  • Total Qty:  1

Slot Required

  • Type:  none

Software

  • Type:  Drivers & Utilities

Dimensions & Weight

  • Width:  4 in
  • Depth:  5.8 in
  • Height:  1 in
  • Weight:  1.32 lbs

Reliability

  • Start / Stop Cycles:  40,000
  • Non-Recoverable Errors:  1 per 10^14

General

  • Manufacturer:  Western Digital Corp.

Additional information

Weight 1.320 lbs
Dimensions 6.000 × 4.000 × 1.000 in
