Description
This is a used Intel Pentium 4 SL683 CPU in good working condition.
General information | |
| Type | CPU / Microprocessor |
| Family | Intel Pentium 4 |
| Part number | BX80532PE2266D |
| Frequency (GHz) | 2.267 |
| Bus speed (MHz) | 533 |
| Clock multiplier | 17 |
| Package type | 478-pin FC-PGA2 |
| Socket type | Socket 478 (mPGA478B) |
Architecture / Microarchitecture / Other | |
| CPUID | 0F24h |
| Core stepping | B0 |
| Processor core | Northwood |
| Manufacturing technology (micron) | 0.13 |
| Number of cores | 1 |
| L2 cache size (KB) | 512 |
| Core voltage (V) | 1.5 |
| Case temperature (°C) | 70 |
Notes on sSpec SL683 | |
| |
Essentials – SL683
- Product Collection: Legacy Intel® Pentium® Processor
- Code Name: Products formerly Northwood
- Vertical Segment: Desktop
- Status: Discontinued
- Lithography: 130 nm
Performance
- # of Cores: 1
- Processor Base Frequency: 2.26 GHz
- Cache: 512 KB L2
- Bus Speed: 533 MHz FSB
- FSB Parity: No
- TDP: 58 W
- VID Voltage Range: 1.355V-1.435V
Supplemental Information – SL683
Package Specifications
- Sockets Supported: PPGA478
- TCASE: 70°C
- Package Size: 35mm x 35mm
- Processing Die Size: 131 mm2
- # of Processing Die Transistors: 55 million
- Low Halogen Options Available: No
Security & Reliability
Certain features may not be available on all computing systems. Please check with the system vendor to determine if your system delivers a specific feature, or reference the system specifications (motherboard, processor, chipset, power supply, HDD, graphics controller, memory, BIOS, drivers, virtual machine monitor-VMM, platform software, and/or operating system) for feature compatibility. Functionality, performance, and other benefits of this feature may vary depending on system configuration.
System and Maximum TDP is based on worst case scenarios. Actual TDP may be lower if not all I/Os for chipsets are used.
Processors that support 64-bit computing on Intel® architecture require an Intel 64 architecture-enabled BIOS.
See http://www.intel.com/content/www/us/en/architecture-and-technology/hyper-threading/hyper-threading-technology.html?wapkw=hyper+threading for more information including details on which processors support Intel® HT Technology.
Max Turbo Frequency refers to the maximum single-core processor frequency that can be achieved with Intel® Turbo Boost Technology. See www.intel.com/technology/turboboost/ for more information.
