Description

This is a used Hard Drive WD400JB in good working condition.

General

• Interface:  ATA-100
• Buffer Size:  8 MB
• Weight:  1.32 lbs
• Manufacturer:  Western Digital Corp.

Interface Provided

• Qty:  1
• Connector Type:  40 pin IDC
• Storage Interface:  ATA-100
• Interface:  ATA-100

Expansion & Connectivity

• Interfaces:  1 x ATA-100 – 40 pin IDC

Hard Drive

• Form Factor:  3.5″ x 1/3H
• Interface Type:  ATA-100
• Spindle Speed:  7200 rpm
• Hard Drive Type:  internal hard drive
• Form Factor (Short):  3.5″
• Form Factor (metric):  8.9 cm x 1/3H
• Form Factor (Short) (metric):  8.9 cm
• Storage Interface:  ATA-100
• Interface:  ATA-100
• Average Seek Time:  8.9 ms
• Max Seek Time:  21 ms
• Track-to-Track Seek Time:  2 ms
• Average Latency:  4.2 ms
• Data Transfer Rate:  100 MBps
• Buffer Size:  8 MB
• Non-Recoverable Errors:  1 per 10^14
• Start / Stop Cycles:  50000

Performance

• Seek Time:  8.9 ms (average) / 21 ms (max)
• Drive Transfer Rate:  100 MBps (external)
• Average Latency:  4.2 ms
• Spindle Speed:  7200 rpm
• Track-to-Track Seek Time:  2 ms

Storage Controller (2nd)

• Type:  none

Environmental Parameters

• Shock Tolerance:  65 g @ 2ms half-sine pulse (operating) / 200 g @ 2ms half-sine pulse (non-operating)
• Min Operating Temperature:  41 °F
• Max Operating Temperature:  131 °F
• Humidity Range Operating:  5 – 85%
• Sound Emission:  35 dBA
• Sound Emission:  35 dBA

Storage Hard Drive

• Compliant Standards:  S.M.A.R.T.

Header

• Brand:  WD
• Product Line:  WD Blue
• Model:  WD400JB
• Packaged Quantity:  1
• Compatibility:  PC

Bay Required

• Type:  internal
• Form Factor:  3.5″ x 1/3H
• Form Factor (metric):  8.9 cm x 1/3H
• Total Qty:  1

Slot Required

• Type:  none

Dimensions & Weight

• Width:  4 in
• Depth:  5.8 in
• Height:  1 in
• Weight:  1.32 lbs

Service & Support

• Type:  2 years warranty (Expired)

Service & Support Details

• Full Contract Period:  2 years (Expired)
• Type:  limited warranty (Expired)

Reliability

• Non-Recoverable Errors:  1 per 10^14
• Start / Stop Cycles:  50,000

General

• Manufacturer:  Western Digital Corp.
